Week 1 quiz
1.
Question 1
When selecting a motor, the
first 4 numbers, for example MR2205, represent what?
1 point
- The max RPM of the motor.
- Outside diameter and height.
- Stator diameter and height.
- Production date in week and
year.
2.
Question 2
What is the voltage of a 4s
battery?
1 point
- 11.1v
- 3.7v
- 12.0v
- 14.8v
3.
Question 3
If you were designing a
quadcopter that was maneuverable in flight, where would you try to locate the
mass in relation to the thrust plane?
1 point
- Centered on the thrust
plane. - Above the thrust plane.
- Below the thrust plane.
4.
Question 4
When a sketch dimension has
“fx:” before it, what does that mean?
1 point
- The dimension is over
defined. - The dimension is driven.
- The dimension can’t be
solved. - The dimension is linked.
5.
Question 5
When using the Marking Menu
in a sketch, what position is the sketch sub menu located?
1 point
- 3 o’clock.
- 12 o’clock.
- 9 o’clock.
- 6 o’clock.
Week 2 quiz
1.
Question 1
What options are available
when using Extend Surface?
1 point
Tangent.
Natural.
Smooth.
Perpendicular.
2.
Question 2
Linking dimensions in a
sketch can be done in what way(s)?
1 point
Through “Change
Parameters”.
Manually entering a
dimension name.
Selecting multiples while
holding CTRL.
Selecting another dimension
on screen.
3.
Question 3
What options are available
for a mirror feature?
1 point
Features
Components
Bodies
Faces
4.
Question 4
When creating a sketch
offset, how do you reverse the direction of the offset?
1 point
Change the offset value to
a negative.
Offset only works outward.
Select “Reverse Offset” in
the properties.
5.
Question 5
What options are available
for “Project Type” in the sketch project to surface tool?
1 point
Normal to Plane
Closest Point
Normal Vector
Along Vector
Week 3 quiz
1.
Question 1
When creating a subdivided
pipe what end types are available?
1 point
Open.
Spike.
Closed.
Square.
2.
Question 2
Once a pipe is created
where in Fusion 360 and you edit the pipe properties?
1 point
Timeline
You can’t edit once created.
Modify menu
Browser
3.
Question 3
What feature in the Sculpt workspace
allows you to joint two subdivided faces together?
1 point
Join
Bridge
Weld
Merge Edge
4.
Question 4
When using soft
modification in the edit form tool, what setting controls how far the edit
affects the subdivided mesh?
1 point
Taper
Spread
Fallout
Falloff
5.
Question 5
Where can you find the
Center of Mass measurement at in Fusion 360?
1 point
Physical material dialog
Inspect tool
Body properties
Measure tool
Week 4 quiz
1.
Question 1
What ways can you add a new
environment to a render scene?
1 point
Double click from the
environment library.
Drag and drop from the
environment library.
Drag and drop from the
appearance library.
Double click from the
appearance library.
2.
Question 2
Where can you adjust the
scene camera settings?
1 point
Scene settings dialog.
Modify menu.
Appearances menu.
Camera settings dialog.
3.
Question 3
When a part has both an
appearance and a physical material applied, which one takes visual priority?
1 point
Appearance
Physical material
4.
Question 4
When a decal is inserted on
a face, what adjustments are available?
1 point
Scale
Translate
White balance
Rotate
5.
Question 5
An in-canvas render
produces an image through what?
1 point
Ray tracing
Cloud processing
Cloud rendering
Course assessment
1.
Question 1
An ESC is an electronic component that goes
between the flight controller and the motor. What does ESC stand for?
1 point
Extended Signal Carrier
Electronic Speed Controller
Electric Speed Circuit
Electronic Signal Center
2.
Question 2
The type of battery used
in most quadcopters is a LiPo because of its good power output and light
weight. There are 3 main variables when
choosing a battery: Voltage, Current,
and Discharge. If I have a LiPo 3S
2000mAh 20-30C battery, how much amperage can it output continuously without
damage?
1 point
60amp
40amp
35amp
20amp
3.
Question 3
Mass on any design can be
critical, but even more so on anything that flies. The overall mass and its location is critical
to performance. If we have 300g worth of
electronic components and 300g worth of body what is the approximate target
weight for a set of batteries assuming 50-65% of the mass is battery? Hint: Solve for two variables. Battery =
X. Total = Y. X = 0.65Y & (300 +
300) = 0.35Y. Solve for Y and then Solve
for X.
1 point
300-600g
600-1100g
500-1000g
550-1200g
4.
Question 4
What is it called when you
insert a design into a current file?
1 point
Linked design
Assembly design
Live design
Distributed design
5.
Question 5
Creating a static rendered
image can be impressive, but a turntable animation can take it to the next
level. What options are available for
number of images in a turntable render?
1 point
6
36
18
12
6.
Question 6
When a sketch line is converted to construction, what happens to its appearance?
1 point
It changes to blue.
It changes to red.
It becomes solid.
It becomes dashed.
7.
Question 7
When a sketch dimension is linked to a parameters, what letters are displayed in front of it?
1 point
Eq.
Ex.
Lk.
Fx.
8.
Question 8
In what workspace do you create a subdivided pipe?
1 point
Model
Sculpt
Patch
Simulation
9.
Question 9
What sculpt feature is used to create a blend between two faces?
1 point
Merge Edge
Bridge
Blend
Combine
10.
Question 10
What is the name of the right click menu to measure a bodies mass?
1 point
Properties
Measure
Mass
Physical Material
Peer-graded Assignment: Model a simple chassis
